雷达液位计 NMR84
Technical Data
CompareContinuous / Liquids
| Measuring Principle | Level radar |
| Characteristic / Application | Planar antenna, 6GHz: High precision measurement for for storage tanks up to 30 m (98ft) |
| Specialities | Custody transfer level measurement |
| Supply / Communication | 85-264VAC 52-74VAC 19-64VDC |
| Accuracy | up to 0.5 mm |
| Ambient temperature | Standard: -40°C…60°C (-40°F...140°F) For calibration to regulatory standards: -25°C…55°C (-13°F...131°F) |
| Process temperature | -40°C…150°C (-40°F...302°F) |
| Process pressure / max. overpressure limit | Vacuum ... 25 bar abs |
| Main wetted parts | 316L, PTFE |
| Process connection | Flange: DN100/4"…DN300/12" UNI-Flange: DN150/6"…DN300/12" |
| Max. measurement distance | 50 m (164 ft) For calibration to regulatory standards: 50 m (164 ft) |
| Communication | Outputs: Fieldbus: Modbus RS485, V1, WM550 HART, BPM and TRL/2 (via GE option) Analog 4-20mA output (Exi/ Exd) Relay output (Exd) Inputs: Analog 4-20mA input (Exi/ Exd) 2-, 3-, 4-wire RTD input Discrete input (Exd, passive/ active) |
| Certificates / Approvals | ATEX, FM, IEC Ex, EAC, JPN Ex, KC Ex, INMETRO, NEPSI, UK Ex |
| Safety approvals | Overfill protection WHG SIL |
| Design approvals | EN 10204-3.1 NACE MR0175, MR0103 AD2000 |
| Metrological approvals and certificates | OIML, NMi, PTB |
| Options | Redundant fieldbus Alu-coated or 316L housing Weather protection cover |
| Application limits | Maximum measuring range is dependent on the tank form and/ or application Strong condensate or build-up formation |
Micropilot NMR84 can be used for custody transfer and inventory control measurements and is certified by NMi and PTB. It complies with the relevant requirements of OIML R85 and API 3.1B. NMR84 is a free-space radar with a planar antenna, particularly suitable for stilling-well applications. The advanced planar antenna design with a verified track record eliminates measurement problems caused by condensation.
Advantages
Hardware and software design in accordance with IEC 61508, maximum safety SIL3 (in homogeneous redundant systems)
Maximum measuring accuracy of ±0.5 mm (±0.02"), therefore maximum reliability
Design complies with international metrology regulations, e.g. OIML R85 and API MPMS standards
Local and national certifications, e.g. NMi or PTB certification for custody transfer applications
Simple connection to higher-level DCS systems via open protocols, easy installation and trouble-free operation
Unique planar antenna design eliminates measurement errors caused by condensation deposits
Application
The planar antenna is particularly suitable for stilling-well applications.
Process connection: flange
Temperature: -40...+150°C (-40...+302°F)
Pressure: vacuum...+25 bar (vacuum...+362 psi)
Maximum measuring range: 40 m (131 ft)
Measuring accuracy: ±0.5 mm (±0.02")
Operating frequency: 6 GHz
International explosion protection and custody transfer certification, WHG overfill protection, SIL certification
Technical documentation
Technical data
Documents/Manuals/Software
Accessories/Spare parts
Source:Endress+Hauserwebsite public information
